Schüco

Aluminum Doors

Home » Products » Aluminium doors » Aluminum Doors Schüco » AD UP 75 BL

AD UP 75 BL –

This is a highly flexible door system with the basic 75 mm depth for stable and seamless use.

The Schuco AD UP 75 BL (standing for ‘Basic Line’) door system is quite beneficial for developers and architects because it provides enhanced durability and stability, perfect design, freedom, functionality, and easy installation.

The item features the triple-shell profile with a double-insulation level. There are also two gasket levels for better weathertightness characteristics.

The clamping anchor technology allows for better adjustment options boosted by the convenient side-hung feature, an aluminum composite threshold with concealed fixing and structurally optimized sealing.

Specifications

AD UP 75 BL

Uf value of frame (≥):	1.9 W / (m²·K)
Wind load resistance:	Class C2 / B2
Watertightness:	Class 5A
Air permeability:	Class 3
Max. vent weight:	200 kg
Min.-max. glass/panel thickness:	13…53 mm
Burglar resistance:	Up to RC 2

Request a quote

All ALUMINUM DOORS Schüco

Our products are primarily:

Durability of at least 80 years

Resistance to corrosion and weather conditions

High level of thermal and acoustic insulation

Environmental friendliness – safe for people and the world.

Our managers will be delighted to answer all your questions
– feel free to contact us!

Why aluminum?

High strength at relatively low density: Our products are engineered to provide exceptional durability while maintaining a lightweight construction, ensuring long-lasting performance without compromising on structural integrity.

Absolute safety for health (not contain harmful components): We prioritize the health and well-being of our customers by using materials free from harmful substances, guaranteeing a safe and healthy environment for all occupants.

Wide variety of temperature modes (functional from -80 to +100 degrees): Designed to withstand extreme temperatures ranging from -80 to +100 degrees Celsius, our products offer reliable performance in diverse environmental conditions, ensuring functionality and comfort year-round.

Have an attractive design look: With meticulous attention to detail, our products boast an elegant and contemporary design, enhancing the visual appeal of any space while complementing various architectural styles and preferences.

Corrosion resistant: Built to withstand the elements, our products feature corrosion-resistant properties, ensuring long-term durability and minimal maintenance requirements, even in challenging environments.
